Bronze Sheet & Plate

•
  C95400 Aluminum Bronze (C954) - Per ASTM B505

  Standards: ASTM B-148, ASTM B-271, ASTM B-505, ASTM B-763, SAE 461, SAE J461, SAE J462, SAE 68A, AMS 4870, AMS 4871, AMS 4635
•
  C93200 Bearing Bronze (SAE660) - C932 Leaded Tin Bronze

  Standards: ASTM B-66, ASTM B-271, ASTM B-505, ASTM B-584, SAE 461, SAE J461, SAE J462, SAE660, DIN 2.1090.03
•
  C63200 Nickel Aluminum Bronze

  ASTM B150, QQ-C-465
•
  C63000 Nickel Aluminum Bronze - AMS 4640 / CDA 630

  Standards: ASTM B-124, ASTM B-150, ASTM B-171, B-283, SAE J461, SAE J463, AMS 4640F, AMS 4880B, DIN 2.0966
•
  C61400 Aluminum Bronze

  SAE J461, ASME SB169, ASTM B169, FEDERAL QQ-C-450, SAE J463
•
  C61300 Aluminum Bronze

  C61300 Typical Uses: Building: Wire Screening, Fasteners, Bolts, Nuts Industrial : Heat Exchanger Tube, Seamless Tubing and Pipe, Tube Sheets, Columns, Sea Water Piping, Mining Shovels, Tie Rods, Condenser Tube, Water Boxes, Corrosion Resistant Vessels, Machine Parts, Piping Systems, Acid Resistant, Gaskets, Tanks, Desalination Equipment Marine: Marine Hardware, Protective Sheathing Ordnance, Mixing Troughs, Blending Chambers Other : Ball Valve Seats
•
  C51000 Phosphor Bronze "5% A"

  EN equivalent isåÊCuSn5 ASTM B139, QQ-B750, SAE J461 C51000 Phosphor Bronze alloy possess a higher yield strength than is readily available in most cast products. Typical applications for phosphor bronze include bearings, bushings, gears, pinions, shafts, thrust washers and valve parts. C51000 Phosphor bronze can be readily brazed or soldered. Capacity for being cold worked is good.
