C83600 Tiger Bronze Alloy Tube
Short Description:
PRODUCT DESCRIPTION:. Leaded Red BrassSOLIDS: 1/2" to 13" OD
TUBES: 1" to 16" OD
RECTANGLES: Up to 20"
STANDARD LENGTHS: 144"
SHAPE/FORM: semi-finished, mill stock or near-net shapes, anode, bar stock, billet/bloom, squares, hex, plate, profile or structural shape, flats/rectangular bar
Send email to us
Download as PDFTypical Uses
ARCHITECTURE: ornamental fixtures
BUILDERS HARDWARE: hardware
BUILDING: cooling equipment, heating equipment, lightning protection, trowels for cement working
ELECTRICAL: electrical equipment, electrical hardware, switches
FASTENERS: large hold-down screws
INDUSTRIAL: air actuators, bearing segments for steel industry, bearings, bushings, couplings, furnaces, handles for dental equipment, impellers, low pressure valves, pressure blocks for steel industry, printing presses, pump fixtures, pump parts, pumps, rings, small gears, transducer housings, valve bodies, valve bodies for the water meter industry, valves, valves for the water meter industry
MARINE: marine products, parts for boats
PLUMBING: faucets, fixtures, pipe fittings
Similar or Equivalent Specification
| CDA | ASTM | SAE | AMS | Federal | Military | Other |
|---|---|---|---|---|---|---|
| C83600 |
B505
B505M
B271
B271M
B62 |
J461
J462 | 4855 |
WW-P-460
WW-U-516 |
MIL-C-11866
MIL-V-18436 | Ounce Metal |
Chemical Composition
| Cu%1 | Pb% | Sn% | Zn% | Fe% | P% | Ni%1,2 | Al% | S% | Sb% | Si% | |
|---|---|---|---|---|---|---|---|---|---|---|---|
Chemical Composition according to ASTM B505/B505M-18
1In determining Cu min., Cu may be calculated as Cu + Ni. 2Ni value includes Co.
Note: Single values represent maximums. | |||||||||||
84.00-
86.00 |
4.00-
6.00 |
4.00-
6.00 |
4.00-
6.00 |
0.30 |
1.50 |
1.00 |
0.005 |
0.08 |
0.25 |
0.005 | |
Machinability
| Copper Alloy UNS No. | Machinability Rating | Density (lb/in3 at 68 °F) |
|---|---|---|
| C83600 | 84 | 0.318 |
Mechanical Properties
Mechanical Properties according to ASTM B505/B505M-18 | |||||||||||
| Tensile Strength, min | Yield Strength, at 0.5% Extension Under Load, min | Elongation, in 2 in. or 50 mm min |
Brinell Hardness (500 kg load) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| ksi | MPa | ksi | MPa | % | typical BHN | ||||||
| 36 | 248 | 19 | 131 | 15 | 60 | ||||||
Physical Properties
Physical Properties provided by CDA | ||
| US Customary | Metric | |
|---|---|---|
| Melting Point - Liquidus | 1850 °F | 1010 °C |
| Melting Point - Solidus | 1570 °F | 854 °C |
| Density | 0.318 lb/in3 at 68 °F | 8.83 gm/cm3 at 20 °C |
| Specific Gravity | 8.83 | 8.83 |
| Electrical Conductivity | 15% IACS at 68 °F | 0.087 MegaSiemens/cm at 20 °C |
| Thermal Conductivity | 41.6 BtuBtu/sq ft/ft hr/°F at 68 °F | 72 W/m at 20 °C |
| Coefficient of Thermal Expansion 68-392 | 10 · 10-6 per °F (68-392 °F) | 17.3 · 10-6 per °C (20-200 °C) |
| Specific Heat Capacity | 0.09 Btu/lb/°F at 68 °F | 377.1 J/kg at 20 °C |
| Modulus of Elasticity in Tension | 13500 ksi | 93100 MPa |
| Magnetic Permeability | 1 | 1 |
