C26000 Cartridge Brass "70/30" (CDA 260)
Short Description:
ASTM B36 (Bar, Sheet, and Plate), ASTM B135 (Tubing), SAE J461
EN equivalent for this alloy CuZn30
Send email to us
Download as PDFTypical Uses for C26000 Cartridge Brass "70/30":
ARCHITECTURE: Grillwork
AUTOMOTIVE: Odometer Contacts, Heater Cores, Thermostats, Electrical Connectors, Radiator Cores, Radiator Tube, Radiator Tanks, Tanks
BUILDERS HARDWARE: Odometer Contacts, Heater Cores, Thermostats, Electrical Connectors, Radiator Cores, Radiator Tube, Radiator Tanks, Tanks
CONSUMER: Snaps, Planters, Fireplace Screens, Etched Articles, Bird Cages, Coinage, Chain Links, Pen/Pencil Inserts and Clips, Syringe Parts, Watch Parts, Costume Jewelry, Buttons, Shells - Electrical Sockets, Lamps
ELECTRICAL: Terminal Connectors, Flashlight Shells, Lamp Fixtures, Reflectors, Screw Shells
FASTENERS: Pins, Rivets, Fasteners, Grommets, Eyelets, Screws
INDUSTRIAL: Air Pressure Conveyer Systems, Sound Proofing Equipment, Springs, Chain, Bead Chain, Tubing for Instruments and Machines, Heat Exchangers, Pump Cylinders, Wire Screens, Pumps, Liners, Power Cylinders
ORDINANCE: Ammunition Cartridge Cases, Mechanical Housings for Lighters, Shells - Mechanical Housings for Ammunition, Ammunition
PLUMBING: Fittings, Bathroom Fixtures, Plumbing Accessories, Faucet Escutcheons, Traps, Plumbing Brass Goods
OTHER: Stencils, Washers
Specifications
| End Product | Specification |
| Bar | ASTM B36, B19, SAE J463, J461 |
| Brazing Filler Metal | FEDERAL QQ-B-650 |
| Cups, Cartridge Case | ASTM B129, MILITARY MIL-C-10375, |
| Disk | ASTM B19 |
| Plate | AMS 4507, 4505, ASTM B19, B36 |
| Rod | SAE J463, J461 |
| Sheet | AMS 4507, 5408, 4505, ASTM B19, B36, SAE J463, J461 |
| Shim Stock, Laminated | MILITARY MIL-S-22499 |
| Strip | AMS 4507, 4505, ASTM B36, B569, B19, B888, SAE J463, J461 |
| Tube, Seamless | ASTM B135, FEDERAL WW-T-791, MILITARY MIL-T-20219, SAE J463, J461 |
| Tube, Welded | ASTM B587, B587 |
| Wire | ASTM B134, SAE J463, J461 |
